SPONGE/FOAM SHREDDER
Key words:
SPONGE/FOAM SHREDDER
Category:
Product Description
AV-500 FOAM SHREDDER 11KW
CUTTERANDCUTTER SADDLE
High-quality alloy cutters, designed in accordance with the principles of mechanics
1. The cutters are processed with high-quality alloy raw materials, with a T10 hardness of HRC50-55 degrees. The installation design of the cutters can be adjusted telescopically, and can be sharpened multiple times after abrasion, which extends the service life.
2. The main shaft adopts high quality 45# carbon steel modulation treatment, and the bearing adopts double row roller spherical bearing.
3. The movable knife seat is made of high-quality raw materials, which are not easy to break or wear. It is firm with high-strength screws, the structure is firm and durable, and has strong mechanical properties.
4. The movable tool holder is designed with a simple stepped design to decompose the cutting force and double the cutting force to ensure super crushing ability.
STRUCTURE DIAGRAM
SPECIFICATION 1、 Rotating blades 2、Reel cap 3、Motor 4、Mesh screen fixture 5、Mesh screen 6、Fixed blades 7、Feed opening 8、Double-layer striker plate 9、Pugging 10、Latter lap
Capacity：100-120kgs/hour.
Power：220V / 60HZ OR 480V / 60HZ FOR OPTION.
SPECIFICATION
| Model |
POWER (kw)/(HP) |
AXIS SPEED （r/min) |
AXIA DIA (mm) |
BLADE AMOUNT (pcs) |
BLADE (pcs) |
CAPACITY (kg/h) |
INNER SIZE (mm) |
G.W (kg) |
MESH DIA (mm) |
OUT SIZE (L*W*H)m |
| AV500 | 11/15 | 600 | 78 | 15 | 2 | 100-150 | 500*285 | 550 | 25 | 1.39*1.02*1.56 |
| AV600 | 15/20 | 506 | 82 | 18 | 4 | 150-200 | 600*315 | 800 | 30 | 1.80*1.17*1.74 |
| AV700 | 22/30 | 493 | 110 | 21 | 4 | 200-300 | 685*430 | 1325 | 30 | 1.85*1.32*2.18 |
| AV800 | 30/40 | 440 | 110 | 24 | 4 | 400-500 | 800*450 | 1800 | 30 | 2.25*1.40*2.60 |
